A comprehensive range of multi-brand cables are available in accordance with some of the most exacting standards in the world, including British Standards, CSA, IEC, VDE and UL. The portfolio includes power, data, control and fire performance cables.

Armoured Cables SWA & AWA

Comprehensive range of steel wire and aluminium wire armoured cables in accordance with BS, EN and IEC are available in low voltage and medium voltage. Typically, the construction of an aluminium and steel wire armoured cable comprises of six components – Conductor, Insulation, Bedding, Armour and voltage.

• Available voltage ratings 0.6/1kV, 6.35/11kV and 19/33kV.
• Available sheath – Polyvinyl Chloride (PVC) or Low Smoke Zero Halogen (LSZH)
• Anti-termite & Anti-rodent version on request

Earthing Cables

Designed for use on earthing circuits, it comes with outer sheath as Green/Yellow for identification as per BS EN 50525-2-31 with nominal voltage as 450/750V. Available conductor size is 1.5, 2.5, 4, 6, 10, 25, 70mm²

• Cable with 600/1000V rating as per IEC 60502-1 & IEC 60332-1 is available on request with MOQ

Instrumentation Cables

Instrumentation cables are used in industries where manufacturing and processing operations are controlled and measured by electronic means. Reliability, robustness and proper shielding is essence for optimal performance and resist electromagnetic interference.

• Product Standard as per BS EN 50288-7
• Performance Standard (Flame/Fire-Test) as per IEC 60332-1
• Available sheath – Polyvinyl Chloride (PVC) or Low Smoke Zero Halogen (LSZH)
• Anti-termite & Anti-rodent version on request
• Outer Black sheath as standard, Orange & Blue sheath on request with a MOQ

Rubber Flexible Cables

H07RN-F are heavy duty rubber flexibles for power supply are designed to withstand weather, medium mechanical and thermal stress. They exhibit oil resistance and a good water proof characteristic.

• Product Standard as per BS EN 50525-2-21
• Operating Temperature -25°C to +90°C
• Outer sheath Black as standard
• Core options – Two/Three/Four/Five
• Voltage 450/750V & 0.6/1kV rated for fixed and protected installation
